Hydraulic Press KSY-150H (15 Ton)

Description
Firstly, the design of our hydraulic press emphasizes energy efficiency, consuming less power and materials while operating with low noise. This helps reduce energy costs, minimizes material waste, and provides a quieter and more comfortable working environment.

Secondly, the machine offers high speed and strong output, delivering exceptional productivity. This ensures that you can complete more tasks in less time, significantly boosting production efficiency. Adjustments to pressure, ram position, and bottom dead center accuracy are also very simple, allowing you to easily make changes as needed to ensure consistent product quality.

In terms of control, we provide two highly secure options: automatic PLC control and dual-hand button operation. The "return to home" feature when the operator's hands are released helps prevent accidents, ensuring safe operation. The dual-hand button operation is a standard feature that requires the operator to press both buttons simultaneously to activate the press, effectively preventing accidental activation.

Lastly, our hydraulic press is equipped with an oil temperature cooling system that uses fan cooling. This maintains the oil temperature below 48°C, reducing pressure loss due to heat and enabling stable, long-term operation.
Features
  • Hydraulic Pressing Machine with low energy consumption, less consumable parts and low noise level.
  • High speed, high output, high efficiency.
  • Easy precise adjustment of Oil pressure, head punch location, and lower dead point.
  • Add on accessories: safety light curtain, die clamp, robot arm, and feeder.
  • Control mold: Auto PLC control, buttons operated by both hands simultaneously, head punch home-return on hands-off, double pressing prevention.
  • Capable of being using as individual operation equipment or one of the serial automatic manufacturing system.
  • Safety operation by both hands simultaneously, head punch returns to orignal position as soon as hands off, time delay between two hands are less than 0.3 seconds.
Specification
MODEL Hydraulic Press KSY-150H (15 Ton)
Pressure Capacity 25~148KN (15ton)
Pressure Range 40~158 kg/cm2
Storke 30~200 mm
Descending Speed 300 mm/sec
Pressing Speed 20 mm/sec
Ascending Speed 270 mm/sec
Power 3Ø AC220V
Motor 2.2 Kw-4P
Table Size 450x380 mm
Body Weight 780 kg
Oil Temperature Cooling
