Description
Hydraulic Press KSY-100H (10 Ton)
Features
- Hydraulic Pressing Machine with low energy consumption, less consumable parts and low noise level.
- High speed, high output, high efficiency.
- Easy precise adjustment of Oil pressure, head punch location, and lower dead point.
- Add on accessories: safety light curtain, die clamp, robot arm, and feeder.
- Control mold: Auto PLC control, buttons operated by both hands simultaneously, head punch home-return on hands-off, double pressing prevention.
- Capable of being using as individual operation equipment or one of the serial automatic manufacturing system.
- Safety operation by both hands simultaneously, head punch returns to orignal position as soon as hands off, time delay between two hands are less than 0.3 seconds.
Specification
| MODEL | Hydraulic Press KSY-100H (10 Ton) |
|---|---|
| Pressure Capacity | 15~98KN (10ton) |
| Pressure Range | 40~154 kg/cm2 |
| Storke | 30~200 mm |
| Descending Speed | 320 mm/sec |
| Pressing Speed | 22 mm/sec |
| Ascending Speed | 330 mm/sec |
| Power | 3Ø AC220V |
| Motor | 2.2 Kw-4P |
| Table Size | 450x320 mm |
| Body Weight | 670 kg |
| Oil Temperature Cooling | ○ |
