Hydraulic Press KSY-040H (4 Ton)

Description
Firstly, this equipment is energy-efficient, consumes fewer materials, and operates with low noise. This allows you to reduce energy costs, minimize material waste, and create a quieter, more comfortable work environment.

Secondly, with high power output, fast speed, and exceptional productivity, the hydraulic press enables you to complete more tasks in less time, effectively boosting production efficiency.

Additionally, adjustments for pressure, punch position, and bottom dead center precision are straightforward, allowing operators to make flexible adjustments to ensure high product quality.

In terms of control options, we offer both PLC automatic control and two-hand button operation, both of which prioritize safety. The press includes a feature where the punch returns to its original position when hands are removed, preventing accidents and ensuring operator safety.

Two-hand button operation is a standard feature, requiring both buttons to be pressed simultaneously to activate the press, thereby preventing accidental activation.

Lastly, the equipment is equipped with an oil cooling system that uses fan cooling to maintain oil temperature below 48°C. This reduces pressure loss caused by temperature rise, allowing the machine to operate stably over extended periods.
Features
  • Hydraulic Pressing Machine with low energy consumption, less consumable parts and low noise level.
  • High speed, high output, high efficiency.
  • Easy precise adjustment of Oil pressure, head punch location, and lower dead point.
  • Add on accessories: safety light curtain, die clamp, robot arm, and feeder.
  • Control mold: Auto PLC control, buttons operated by both hands simultaneously, head punch home-return on hands-off, double pressing prevention.
  • Capable of being using as individual operation equipment or one of the serial automatic manufacturing system.
  • Safety operation by both hands simultaneously, head punch returns to orignal position as soon as hands off, time delay between two hands are less than 0.3 seconds.
Specification
MODEL Hydraulic Press KSY-040H (4 Ton)
Pressure Capacity 8~40 KN (4ton)
Pressure Range 25~128 kg/cm2
Storke 25~150 mm
Descending Speed 300 mm/sec
Pressing Speed 50 mm/sec
Ascending Speed 270 mm/sec
Power 3Ø AC220V
Motor 1.5Kw-4P
Table Size 450x270 mm
Body Weight 360 kg
Oil Temperature Cooling
