Hydraulic Press KSY-015H (1.5 Ton)

Description
Firstly, our hydraulic machines are energy-saving, consume less material, and produce low noise. This means that you can reduce energy costs and material waste during the production process while providing a more comfortable working environment.

Secondly, our hydraulic machines are fast, have high output, and achieve high productivity efficiency. This ensures that you can complete more work in a shorter amount of time, thus increasing production efficiency.

Adjusting hydraulic pressure, punch head position, and lower dead point locating device is also very simple and easy. You can easily adjust them as needed to ensure product quality.

Regarding control methods, we provide automatic PLC control and two-hand button operation, both of which are highly secure. The feature of the punch head returning to its original position when hands are removed prevents accidents and ensures operator safety.

Two-hand button operation is a standard feature of our machine models, ensuring that operators must simultaneously press two buttons to activate the punch press, thus avoiding accidental punching incidents.

Finally, our hydraulic punching machines are equipped with an oil temperature cooling device, which uses fan cooling to ensure that the oil temperature does not exceed 48°C. This reduces losses caused by temperature rise and allows for stable operation over a long period of time.
Features
  • Hydraulic Pressing Machine with low energy consumption, less consumable parts and low noise level.
  • High speed, high output, high efficiency.
  • Easy precise adjustment of Oil pressure, head punch location, and lower dead point.
  • Add on accessories: safety light curtain, die clamp, robot arm, and feeder.
  • Control mold: Auto PLC control, buttons operated by both hands simultaneously, head punch home-return on hands-off, double pressing prevention.
  • Capable of being using as individual operation equipment or one of the serial automatic manufacturing system.
  • Safety operation by both hands simultaneously, head punch returns to orignal position as soon as hands off, time delay between two hands are less than 0.3 seconds.
Specification
MODEL Hydraulic Press KSY-015H (1.5 Ton)
Pressure Capacity 2.5~15 KN (1.5ton)
Pressure Range 20~120 kg/cm2
Storke 20~150 mm
Descending Speed 180 mm/sec
Pressing Speed 50 mm/sec
Ascending Speed 190 mm/sec
Power 3Ø AC220V
Motor 0.75Kw-4P
Table Size 450x270 mm
Body Weight 220 kg
Oil Temperature Cooling
